Applications
Industry Applications
As one of the most fundamental components in mechanical transmission systems, bearings are widely used across nearly every industry involving rotational or linear motion, including automotive, industrial manufacturing, energy, aerospace, medical devices, and consumer electronics. From deep groove ball bearings and angular contact ball bearings to cylindrical roller bearings, tapered roller bearings, spherical roller bearings, needle roller bearings, thin section bearings, four-point contact bearings, and thrust bearings, each bearing type employs a distinct structural design to address specific operating requirements — including radial loads, axial loads, combined loading, high-speed rotation, heavy shock loading, and compact installation space — providing precise rotational support for stable equipment operation.
As manufacturing continues to advance toward higher precision, greater reliability, and energy efficiency, the bearing industry is also driving continuous innovation in material technology (such as high-purity bearing steel and ceramic hybrid bearings), sealing protection, low-noise design, and extended service life — meeting the increasingly demanding performance requirements of emerging fields such as wind power, new energy vehicles, robotics, and high-end equipment manufacturing.
FAQs
What loads can deep groove ball bearings handle?
Deep groove ball bearings are primarily designed for radial loads, but they can also handle moderate axial (thrust) loads in both directions. They are not suitable for heavy axial loads or combined shock loads. In those cases, angular contact or tapered roller bearings are preferred.
How do I select the right bearing size for my application?
Selection should be based on bore diameter (shaft size), required load capacity (dynamic rating C and static rating C0), operating speed compared with the bearing limiting speed, available space (outer diameter and width), and required precision grade from P0 to P2. Always apply a safety factor and verify that the calculated L10 service life meets your requirements.
What is the difference between open, shielded (ZZ), and sealed (2RS) bearings?
Open: No built-in protection, requires external sealing, and is suitable for clean environments or oil bath lubrication.
ZZ metal shields: Protect against dust and debris with low friction, making them suitable for high-speed applications, but they are not waterproof.
2RS rubber seals: Provide strong protection against dust and moisture. They are pre-greased and ideal for contaminated environments, but generate slightly more friction.
How often should I lubricate or replace the grease?
For general industrial use, grease should be replenished or replaced every 3,000 to 10,000 operating hours depending on speed, temperature, and environmental conditions. Bearings running above 70 C or in contaminated environments require shorter intervals. Sealed 2RS bearings are pre-greased for life and do not require re-lubrication.
What are the common causes of premature bearing failure?
The most frequent causes include inadequate or improper lubrication, contamination by dirt, dust, or moisture, incorrect installation, misalignment, excessive force during fitting, overloading beyond the rated capacity, improper shaft or housing fits, and fatigue at the end of normal service life.
How is the rated service life (L10) of a bearing calculated?
The basic L10 life is calculated as L10 = (C / P)^3 x 10^6 revolutions, where C is the dynamic load rating in kN and P is the equivalent dynamic bearing load in kN. It represents the number of revolutions that 90% of identical bearings will complete without fatigue failure. In practice, ISO 281 modified life calculations also apply correction factors for lubrication, contamination, material, and reliability.
